前言
在机器学习的场景中,训练数据经常会特别大,训练可能要持续好几天甚至上周。如果中途机器断电或是发生意外不得不中断训练过程,那就得不偿失。
使用keras 高阶API,可以很简单的保存训练现场,可以让我们很容易的恢复到上次落下的地方继续训练。
思路
存在两个巨大的问题:
继续训练会有这样一个影响,就是我们的学习率如果是不固定的,比如前100 epoch 学习率0.1,后100 epoch 学习率要0.01,这样的话,epoch这个数据比需要被记录下来。
如果设save_best_only=True
,会一遍遍覆盖旧的.h5
文件,当重新加载的时候,self.best
是正负无穷(正负取决于mointor
是val_loss
还是val_acc
等)
要做到从上次落下的地方继续训练,首先需要明确我们保存模型的方法是什么!
保存全部训练数据(save_weights_only=False
) or 只保存weights(save_weights_only=True
)
保存最棒的版本(save_best_only=True
) or 保存最新的版本(save_best_only=False
)
新.h5
文件覆盖老的文件 or 每一个文件都使用epoch
区别开来
使用'./path/to/somename-{epoch:04d}.h5'.
作为文件名即可使得每次存储的文件名都有个epoch
数作为后缀。
原因在于,在keras/callbacks.py
中源码是如此定义的:
def on_epoch_end (self, epoch, logs=None ): logs = logs or {} 。。。。。。 filepath = self.filepath.format (epoch=epoch + 1 , **logs)
其次,我们必须知道继续训练 的充要条件是什么:
知道在中断时,执行到哪一个epoch
,
知道在中断时,最高的val_acc
或最小的val_loss
是多少
针对上面提出来的7点问题,我们下文将探讨如何设计一个能满足上述要求的方法。
导入相关依赖
from keras.callbacks import ModelCheckpointimport h5pyimport numpy as npimport keras
上述引入使用的是keras
自身API,如果您需要使用tensorflow.keras
请导入如下依赖:
from tensorflow.keras.callbacks import ModelCheckpointimport h5pyimport numpy as npfrom tensorflow import keras
其中ModelCheckpoint
就是我们今天的猪脚。
有关于更多callback
的内容,请参阅官方文档:https://keras-cn.readthedocs.io/en/latest/other/callbacks/
准备训练数据
为了快速演示,我们使用mnist数据集
(train_images, train_labels), (test_images, test_labels) = keras.datasets.mnist.load_data() train_labels = train_labels[:1000 ] test_labels = test_labels[:1000 ] train_images = train_images[:1000 ].reshape(-1 , 28 * 28 ) / 255.0 test_images = test_images[:1000 ].reshape(-1 , 28 * 28 ) / 255.0
如果下载数据集的过程中出现问题,请选择代理 或 在keras api
和tensorflow.keras
之间切换,前者将数据托管在amazon上,后者在google上。请酌情选择。
构建一个简单的神经网络
def create_model (): model = keras.models.Sequential([ keras.layers.Dense(512 , activation="relu" , input_shape=(784 ,)), keras.layers.Dropout(0.2 ), keras.layers.Dense(10 , activation="softmax" ) ]) model.compile (optimizer=keras.optimizers.Adam(), loss=keras.losses.sparse_categorical_crossentropy, metrics=['accuracy' ]) return model model = create_model() model.summary()
_________________________________________________________________ Layer (type) Output Shape Param # ================================================================= dense_1 (Dense) (None, 512) 401920 _________________________________________________________________ dropout_1 (Dropout) (None, 512) 0 _________________________________________________________________ dense_2 (Dense) (None, 10) 5130 ================================================================= Total params: 407,050 Trainable params: 407,050 Non-trainable params: 0
准备输出
创建h5模型输出的目录
import osif not os.path.exists('./results/' ): os.mkdir('./results/' )
从ModelCheckpoint
继承一个子类用于拓展
class MetaCheckpoint (ModelCheckpoint ): def __init__ (self, filepath, monitor='val_loss' , verbose=0 , save_best_only=False , save_weights_only=False , mode='auto' , period=1 , training_args=None , meta=None ): super (MetaCheckpoint, self).__init__(filepath, monitor=monitor, verbose=verbose, save_best_only=save_best_only, save_weights_only=save_weights_only, mode=mode, period=period) self.filepath = filepath self.new_file_override = True self.meta = meta or {'epochs' : [], self.monitor: []} if training_args: self.meta['training_args' ] = training_args def on_train_begin (self, logs={} ): if self.save_best_only: if 'acc' in self.monitor or self.monitor.startswith('fmeasure' ): self.best = max (self.meta[self.monitor], default=-np.Inf) else : self.best = min (self.meta[self.monitor], default=np.Inf) super (MetaCheckpoint, self).on_train_begin(logs) def on_epoch_end (self, epoch, logs={} ): if self.save_best_only: current = logs.get(self.monitor) if self.monitor_op(current, self.best): self.new_file_override = True else : self.new_file_override = False super (MetaCheckpoint, self).on_epoch_end(epoch, logs) self.meta['epochs' ].append(epoch) for k, v in logs.items(): self.meta.setdefault(k, []).append(v) filepath = self.filepath.format (epoch=epoch, **logs) if self.new_file_override and self.epochs_since_last_save == 0 : with h5py.File(filepath, 'r+' ) as f: meta_group = f.create_group('meta' ) meta_group.attrs['training_args' ] = yaml.dump( self.meta.get('training_args' , '{}' )) meta_group.create_dataset('epochs' , data=np.array(self.meta['epochs' ])) for k in logs: meta_group.create_dataset(k, data=np.array(self.meta[k]))
其中meta
是.h5
文件里面的group
,意思就是指训练过程中的数据信息,相当于一个数据子集,和data
,label
等并列。
下面我将讲解MetaCheckpoint
的关键代码
在类初始化的时候,初始化epochs
,和monitor
(一般即val_acc
或val_loss
)
self.meta = meta or {'epochs' : [], self.monitor: []}
on_train_begin
当训练开始的时候,如果是save_best_only
状态的话
self.best = max (self.meta[self.monitor], default=-np.Inf)
把最优值赋值为meta
里面保存的最优值
如果越小越优的话:
self.best = min (self.meta[self.monitor], default=np.Inf)
反过来即可。
on_epoch_end
在一个epoch训练结束之后:
self.meta['epochs' ].append(epoch)
把结果附加到meta
里面去
然后视情况而定,是否要保存到.h5
文件
self.new_file_override
说明经过判断,认为此次训练产生了更好的val_acc
或val_loss
(取决于你的设定),best
值被更新。
self.epochs_since_last_save == 0
说明模型文件已经存储至你指定的路径。
如果满足以上两点要求,我们就可以往模型文件里面附加本次训练的meta
数据。
调用
第一次训练
创建MetaCheckpoint
实例
checkpoint = MetaCheckpoint('./results/pointnet.h5' , monitor='val_acc' , save_weights_only=True , save_best_only=True , verbose=1 )
开始训练:
model.fit(train_images, train_labels, epochs = 10 , validation_data = (test_images,test_labels), callbacks = [checkpoint])
Train on 1000 samples, validate on 1000 samples Epoch 1/10 1000/1000 [==============================] - 0s 454us/step - loss: 1.1586 - acc: 0.6590 - val_loss: 0.7095 - val_acc: 0.7770 Epoch 00001: val_acc improved from -inf to 0.77700, saving model to ./results/pointnet.h5 Epoch 2/10 1000/1000 [==============================] - 0s 321us/step - loss: 0.4256 - acc: 0.8780 - val_loss: 0.5295 - val_acc: 0.8320 Epoch 00002: val_acc improved from 0.77700 to 0.83200, saving model to ./results/pointnet.h5 Epoch 3/10 1000/1000 [==============================] - 0s 305us/step - loss: 0.2859 - acc: 0.9240 - val_loss: 0.4457 - val_acc: 0.8620 Epoch 00003: val_acc improved from 0.83200 to 0.86200, saving model to ./results/pointnet.h5 Epoch 4/10 1000/1000 [==============================] - 0s 319us/step - loss: 0.2093 - acc: 0.9570 - val_loss: 0.4540 - val_acc: 0.8540 Epoch 00004: val_acc did not improve from 0.86200 Epoch 5/10 1000/1000 [==============================] - 0s 295us/step - loss: 0.1518 - acc: 0.9670 - val_loss: 0.4261 - val_acc: 0.8650 Epoch 00005: val_acc improved from 0.86200 to 0.86500, saving model to ./results/pointnet.h5 Epoch 6/10 1000/1000 [==============================] - 0s 268us/step - loss: 0.1101 - acc: 0.9850 - val_loss: 0.4211 - val_acc: 0.8570 Epoch 00006: val_acc did not improve from 0.86500 Epoch 7/10 1000/1000 [==============================] - 0s 350us/step - loss: 0.0838 - acc: 0.9900 - val_loss: 0.4040 - val_acc: 0.8700 Epoch 00007: val_acc improved from 0.86500 to 0.87000, saving model to ./results/pointnet.h5 Epoch 8/10 1000/1000 [==============================] - 0s 261us/step - loss: 0.0680 - acc: 0.9920 - val_loss: 0.4097 - val_acc: 0.8660 Epoch 00008: val_acc did not improve from 0.87000 Epoch 9/10 1000/1000 [==============================] - 0s 272us/step - loss: 0.0530 - acc: 0.9960 - val_loss: 0.4001 - val_acc: 0.8750 Epoch 00009: val_acc improved from 0.87000 to 0.87500, saving model to ./results/pointnet.h5 Epoch 10/10 1000/1000 [==============================] - 0s 306us/step - loss: 0.0392 - acc: 0.9980 - val_loss: 0.3981 - val_acc: 0.8670 Epoch 00010: val_acc did not improve from 0.87500
查看保存的模型
定义一个函数来加载meta
数据:
import yamldef load_meta (model_fname ): ''' Load meta configuration ''' meta = {} with h5py.File(model_fname, 'r' ) as f: meta_group = f['meta' ] meta['training_args' ] = yaml.load( meta_group.attrs['training_args' ]) for k in meta_group.keys(): meta[k] = list (meta_group[k]) return meta
调用之:
last_meta = load_meta("./results/pointnet.h5" ) last_meta
{'acc': [0.659, 0.878, 0.924, 0.957, 0.967, 0.985, 0.99, 0.992, 0.996], 'epochs': [0, 1, 2, 3, 4, 5, 6, 7, 8], 'loss': [1.158559440612793, 0.4256118061542511, 0.28586792707443237, 0.2092902910709381, 0.1517823133468628, 0.11005254900455474, 0.08378619635850192, 0.06799231326580048, 0.05295254367589951], 'training_args': '{}', 'val_acc': [0.777, 0.832, 0.862, 0.854, 0.865, 0.857, 0.87, 0.866, 0.875], 'val_loss': [0.7094822826385498, 0.5294894614219665, 0.44566395616531373, 0.454044997215271, 0.426121289730072, 0.42110520076751706, 0.4039662191867828, 0.4096675853729248, 0.40012847566604615]}
可以轻易看出epochs
只记录到第八次,因为我们save_best_only
.
中断实验
手动删除.h5
模型文件
然后回到上一次fit
的时候
model.fit(train_images, train_labels, epochs = 10 , validation_data = (test_images,test_labels), callbacks = [checkpoint])
运行过程中强行结束:
Train on 1000 samples, validate on 1000 samples Epoch 1/10 1000/1000 [==============================] - 0s 445us/step - loss: 1.1578 - acc: 0.6580 - val_loss: 0.7134 - val_acc: 0.7900 Epoch 00001: val_acc improved from -inf to 0.79000, saving model to ./results/pointnet.h5 Epoch 2/10 448/1000 [============>.................] - ETA: 0s - loss: 0.4623 - acc: 0.8862 KeyboardInterruptTraceback (most recent call last) <ipython-input-23-e27c5787d098> in <module> 1 model.fit(train_images, train_labels, epochs = 10, 2 validation_data = (test_images,test_labels),----> 3 callbacks = [checkpoint]) 。。。more ouput。。。
再执行
last_meta = load_meta("./results/pointnet.h5" ) last_meta
{'acc': [0.658], 'epochs': [0], 'loss': [1.1578046548366547], 'training_args': '{}', 'val_acc': [0.79], 'val_loss': [0.7134194440841675]}
果然,就记录到第1次输出的时候。
创建一个函数来加载关键数据:
def get_last_status (model ): last_epoch = -1 last_meta = {} if os.path.exists("./results/pointnet.h5" ): model.load_weights("./results/pointnet.h5" ) last_meta = load_meta("./results/pointnet.h5" ) last_epoch = last_meta.get('epochs' )[-1 ] return last_epoch, last_meta
last_epoch, last_meta = get_last_status(model) last_epoch
这个输出结果是正确的,我们只要从,第last_epoch+1
次继续训练就好。val_acc
或val_loss
等都会被妥善在on_train_begin
时处理好。
再次构建一个带有meta
属性的回调函数:
checkpoint = MetaCheckpoint('./results/pointnet.h5' , monitor='val_acc' , save_weights_only=True , save_best_only=True , verbose=1 , meta=last_meta)
重新训练:(指定起始epoch)
model.fit(train_images, train_labels, epochs = 10 , validation_data = (test_images,test_labels), callbacks = [checkpoint], initial_epoch=last_epoch+1 )
Train on 1000 samples, validate on 1000 samples Epoch 2/10 1000/1000 [==============================] - 0s 308us/step - loss: 0.4211 - acc: 0.8840 - val_loss: 0.5157 - val_acc: 0.8450 Epoch 00002: val_acc improved from 0.79000 to 0.84500, saving model to ./results/pointnet.h5 Epoch 3/10 1000/1000 [==============================] - 0s 274us/step - loss: 0.2882 - acc: 0.9220 - val_loss: 0.5238 - val_acc: 0.8240 Epoch 00003: val_acc did not improve from 0.84500 Epoch 4/10 1000/1000 [==============================] - 0s 277us/step - loss: 0.2098 - acc: 0.9500 - val_loss: 0.4674 - val_acc: 0.8470 Epoch 00004: val_acc improved from 0.84500 to 0.84700, saving model to ./results/pointnet.h5 Epoch 5/10 1000/1000 [==============================] - 0s 275us/step - loss: 0.1503 - acc: 0.9680 - val_loss: 0.4215 - val_acc: 0.8640 Epoch 00005: val_acc improved from 0.84700 to 0.86400, saving model to ./results/pointnet.h5 Epoch 6/10 1000/1000 [==============================] - 0s 279us/step - loss: 0.1081 - acc: 0.9830 - val_loss: 0.4051 - val_acc: 0.8680 Epoch 00006: val_acc improved from 0.86400 to 0.86800, saving model to ./results/pointnet.h5 Epoch 7/10 1000/1000 [==============================] - 0s 272us/step - loss: 0.0761 - acc: 0.9920 - val_loss: 0.4186 - val_acc: 0.8650 Epoch 00007: val_acc did not improve from 0.86800 Epoch 8/10 1000/1000 [==============================] - 0s 269us/step - loss: 0.0558 - acc: 0.9970 - val_loss: 0.4088 - val_acc: 0.8700 Epoch 00008: val_acc improved from 0.86800 to 0.87000, saving model to ./results/pointnet.h5 Epoch 9/10 1000/1000 [==============================] - 0s 269us/step - loss: 0.0486 - acc: 0.9990 - val_loss: 0.3960 - val_acc: 0.8730 Epoch 00009: val_acc improved from 0.87000 to 0.87300, saving model to ./results/pointnet.h5 Epoch 10/10 1000/1000 [==============================] - 0s 266us/step - loss: 0.0354 - acc: 1.0000 - val_loss: 0.4058 - val_acc: 0.8700 Epoch 00010: val_acc did not improve from 0.87300
可以看见,确实是从第2个epoch开始训练的。
这!就是我们想要的效果。
完整的程序
https://github.com/HarborZeng/resume_traning
