机器学习tensorflow-keras之如何优雅的从上次断掉的地方继续训练

前言

在机器学习的场景中,训练数据经常会特别大,训练可能要持续好几天甚至上周。如果中途机器断电或是发生意外不得不中断训练过程,那就得不偿失。

使用keras 高阶API,可以很简单的保存训练现场,可以让我们很容易的恢复到上次落下的地方继续训练。

思路

存在两个巨大的问题:

  1. 继续训练会有这样一个影响,就是我们的学习率如果是不固定的,比如前100 epoch 学习率0.1,后100 epoch 学习率要0.01,这样的话,epoch这个数据比需要被记录下来。

  2. 如果设save_best_only=True,会一遍遍覆盖旧的.h5文件,当重新加载的时候,self.best是正负无穷(正负取决于mointorval_loss还是val_acc等)

要做到从上次落下的地方继续训练,首先需要明确我们保存模型的方法是什么!

  1. 保存全部训练数据(save_weights_only=False) or 只保存weights(save_weights_only=True)

  2. 保存最棒的版本(save_best_only=True) or 保存最新的版本(save_best_only=False)

  3. .h5文件覆盖老的文件 or 每一个文件都使用epoch区别开来

使用'./path/to/somename-{epoch:04d}.h5'.作为文件名即可使得每次存储的文件名都有个epoch数作为后缀。

原因在于,在keras/callbacks.py中源码是如此定义的:

def on_epoch_end(self, epoch, logs=None):
    logs = logs or {}
    。。。。。。
        filepath = self.filepath.format(epoch=epoch + 1, **logs)

其次,我们必须知道继续训练的充要条件是什么:

  1. 知道在中断时,执行到哪一个epoch
  2. 知道在中断时,最高的val_acc或最小的val_loss是多少

针对上面提出来的7点问题,我们下文将探讨如何设计一个能满足上述要求的方法。

导入相关依赖

from keras.callbacks import ModelCheckpoint
import h5py
import numpy as np
import keras

上述引入使用的是keras自身API,如果您需要使用tensorflow.keras请导入如下依赖:

from tensorflow.keras.callbacks import ModelCheckpoint
import h5py
import numpy as np
from tensorflow import keras

其中ModelCheckpoint就是我们今天的猪脚。

有关于更多callback的内容,请参阅官方文档:https://keras-cn.readthedocs.io/en/latest/other/callbacks/

准备训练数据

为了快速演示,我们使用mnist数据集

(train_images, train_labels), (test_images, test_labels) = keras.datasets.mnist.load_data()

train_labels = train_labels[:1000]
test_labels = test_labels[:1000]

train_images = train_images[:1000].reshape(-1, 28 * 28) / 255.0
test_images = test_images[:1000].reshape(-1, 28 * 28) / 255.0

如果下载数据集的过程中出现问题,请选择代理 或 在keras apitensorflow.keras之间切换,前者将数据托管在amazon上,后者在google上。请酌情选择。

构建一个简单的神经网络

# Returns a short sequential model
def create_model():
  model = keras.models.Sequential([
    keras.layers.Dense(512, activation="relu", input_shape=(784,)),
    keras.layers.Dropout(0.2),
    keras.layers.Dense(10, activation="softmax")
  ])

  model.compile(optimizer=keras.optimizers.Adam(),
                loss=keras.losses.sparse_categorical_crossentropy,
                metrics=['accuracy'])

  return model

# Create a basic model instance
model = create_model()
model.summary()
_________________________________________________________________
Layer (type)                 Output Shape              Param #
=================================================================
dense_1 (Dense)              (None, 512)               401920
_________________________________________________________________
dropout_1 (Dropout)          (None, 512)               0
_________________________________________________________________
dense_2 (Dense)              (None, 10)                5130
=================================================================
Total params: 407,050
Trainable params: 407,050
Non-trainable params: 0
model = create_model()

准备输出

创建h5模型输出的目录

import os
if not os.path.exists('./results/'):
    os.mkdir('./results/')

ModelCheckpoint继承一个子类用于拓展

class MetaCheckpoint(ModelCheckpoint):
    def __init__(self, filepath, monitor='val_loss', verbose=0,
                 save_best_only=False, save_weights_only=False,
                 mode='auto', period=1, training_args=None, meta=None):

        super(MetaCheckpoint, self).__init__(filepath,
                                             monitor=monitor,
                                             verbose=verbose,
                                             save_best_only=save_best_only,
                                             save_weights_only=save_weights_only,
                                             mode=mode,
                                             period=period)

        self.filepath = filepath
        self.new_file_override = True
        self.meta = meta or {'epochs': [], self.monitor: []}

        if training_args:
            self.meta['training_args'] = training_args

    def on_train_begin(self, logs={}):
        if self.save_best_only:
            if 'acc' in self.monitor or self.monitor.startswith('fmeasure'):
                self.best = max(self.meta[self.monitor], default=-np.Inf)
            else:
                self.best = min(self.meta[self.monitor], default=np.Inf)

        super(MetaCheckpoint, self).on_train_begin(logs)

    def on_epoch_end(self, epoch, logs={}):
        # 只有在‘只保存’最优版本且生成新的.h5文件的情况下
        if self.save_best_only:
            current = logs.get(self.monitor)
            if self.monitor_op(current, self.best):
                self.new_file_override = True
            else:
                self.new_file_override = False

        super(MetaCheckpoint, self).on_epoch_end(epoch, logs)

        # Get statistics
        self.meta['epochs'].append(epoch)
        for k, v in logs.items():
            # Get default gets the value or sets (and gets) the default value
            self.meta.setdefault(k, []).append(v)

        # Save to file
        filepath = self.filepath.format(epoch=epoch, **logs)

        if self.new_file_override and self.epochs_since_last_save == 0:
            # 只有在‘只保存’最优版本且生成新的.h5文件的情况下 才会继续添加meta
            with h5py.File(filepath, 'r+') as f:
                meta_group = f.create_group('meta')
                meta_group.attrs['training_args'] = yaml.dump(
                    self.meta.get('training_args', '{}'))
                meta_group.create_dataset('epochs', data=np.array(self.meta['epochs']))
                for k in logs:
                    meta_group.create_dataset(k, data=np.array(self.meta[k]))

其中meta.h5文件里面的group,意思就是指训练过程中的数据信息,相当于一个数据子集,和datalabel等并列。

下面我将讲解MetaCheckpoint的关键代码

讲解MetaCheckpoint的关键代码

在类初始化的时候,初始化epochs,和monitor(一般即val_accval_loss)

self.meta = meta or {'epochs': [], self.monitor: []}

on_train_begin当训练开始的时候,如果是save_best_only状态的话

self.best = max(self.meta[self.monitor], default=-np.Inf)

把最优值赋值为meta里面保存的最优值

如果越小越优的话:

self.best = min(self.meta[self.monitor], default=np.Inf)

反过来即可。

on_epoch_end在一个epoch训练结束之后:

self.meta['epochs'].append(epoch)

把结果附加到meta里面去

然后视情况而定,是否要保存到.h5文件

  1. self.new_file_override说明经过判断,认为此次训练产生了更好的val_accval_loss(取决于你的设定),best值被更新。
  2. self.epochs_since_last_save == 0说明模型文件已经存储至你指定的路径。

如果满足以上两点要求,我们就可以往模型文件里面附加本次训练的meta数据。

调用

第一次训练

创建MetaCheckpoint实例

checkpoint = MetaCheckpoint('./results/pointnet.h5', monitor='val_acc',
                            save_weights_only=True, save_best_only=True,
                            verbose=1)

开始训练:

model.fit(train_images, train_labels, epochs = 10,
          validation_data = (test_images,test_labels),
          callbacks = [checkpoint]) ## 调用callbacks
Train on 1000 samples, validate on 1000 samples
Epoch 1/10
1000/1000 [==============================] - 0s 454us/step - loss: 1.1586 - acc: 0.6590 - val_loss: 0.7095 - val_acc: 0.7770

Epoch 00001: val_acc improved from -inf to 0.77700, saving model to ./results/pointnet.h5
Epoch 2/10
1000/1000 [==============================] - 0s 321us/step - loss: 0.4256 - acc: 0.8780 - val_loss: 0.5295 - val_acc: 0.8320

Epoch 00002: val_acc improved from 0.77700 to 0.83200, saving model to ./results/pointnet.h5
Epoch 3/10
1000/1000 [==============================] - 0s 305us/step - loss: 0.2859 - acc: 0.9240 - val_loss: 0.4457 - val_acc: 0.8620

Epoch 00003: val_acc improved from 0.83200 to 0.86200, saving model to ./results/pointnet.h5
Epoch 4/10
1000/1000 [==============================] - 0s 319us/step - loss: 0.2093 - acc: 0.9570 - val_loss: 0.4540 - val_acc: 0.8540

Epoch 00004: val_acc did not improve from 0.86200
Epoch 5/10
1000/1000 [==============================] - 0s 295us/step - loss: 0.1518 - acc: 0.9670 - val_loss: 0.4261 - val_acc: 0.8650

Epoch 00005: val_acc improved from 0.86200 to 0.86500, saving model to ./results/pointnet.h5
Epoch 6/10
1000/1000 [==============================] - 0s 268us/step - loss: 0.1101 - acc: 0.9850 - val_loss: 0.4211 - val_acc: 0.8570

Epoch 00006: val_acc did not improve from 0.86500
Epoch 7/10
1000/1000 [==============================] - 0s 350us/step - loss: 0.0838 - acc: 0.9900 - val_loss: 0.4040 - val_acc: 0.8700

Epoch 00007: val_acc improved from 0.86500 to 0.87000, saving model to ./results/pointnet.h5
Epoch 8/10
1000/1000 [==============================] - 0s 261us/step - loss: 0.0680 - acc: 0.9920 - val_loss: 0.4097 - val_acc: 0.8660

Epoch 00008: val_acc did not improve from 0.87000
Epoch 9/10
1000/1000 [==============================] - 0s 272us/step - loss: 0.0530 - acc: 0.9960 - val_loss: 0.4001 - val_acc: 0.8750

Epoch 00009: val_acc improved from 0.87000 to 0.87500, saving model to ./results/pointnet.h5
Epoch 10/10
1000/1000 [==============================] - 0s 306us/step - loss: 0.0392 - acc: 0.9980 - val_loss: 0.3981 - val_acc: 0.8670

Epoch 00010: val_acc did not improve from 0.87500

查看保存的模型

定义一个函数来加载meta数据:

import yaml
def load_meta(model_fname):
    ''' Load meta configuration
    '''
    meta = {}

    with h5py.File(model_fname, 'r') as f:
        meta_group = f['meta']

        meta['training_args'] = yaml.load(
            meta_group.attrs['training_args'])
        for k in meta_group.keys():
            meta[k] = list(meta_group[k])

    return meta

调用之:

last_meta = load_meta("./results/pointnet.h5")
last_meta
{'acc': [0.659, 0.878, 0.924, 0.957, 0.967, 0.985, 0.99, 0.992, 0.996],
 'epochs': [0, 1, 2, 3, 4, 5, 6, 7, 8],
 'loss': [1.158559440612793,
  0.4256118061542511,
  0.28586792707443237,
  0.2092902910709381,
  0.1517823133468628,
  0.11005254900455474,
  0.08378619635850192,
  0.06799231326580048,
  0.05295254367589951],
 'training_args': '{}',
 'val_acc': [0.777, 0.832, 0.862, 0.854, 0.865, 0.857, 0.87, 0.866, 0.875],
 'val_loss': [0.7094822826385498,
  0.5294894614219665,
  0.44566395616531373,
  0.454044997215271,
  0.426121289730072,
  0.42110520076751706,
  0.4039662191867828,
  0.4096675853729248,
  0.40012847566604615]}

可以轻易看出epochs只记录到第八次,因为我们save_best_only.

中断实验

手动删除.h5模型文件

然后回到上一次fit的时候

model.fit(train_images, train_labels, epochs = 10,
          validation_data = (test_images,test_labels),
          callbacks = [checkpoint])

运行过程中强行结束:

Train on 1000 samples, validate on 1000 samples
Epoch 1/10
1000/1000 [==============================] - 0s 445us/step - loss: 1.1578 - acc: 0.6580 - val_loss: 0.7134 - val_acc: 0.7900

Epoch 00001: val_acc improved from -inf to 0.79000, saving model to ./results/pointnet.h5
Epoch 2/10
 448/1000 [============>.................] - ETA: 0s - loss: 0.4623 - acc: 0.8862

KeyboardInterruptTraceback (most recent call last)
 in
      1 model.fit(train_images, train_labels,  epochs = 10,
      2           validation_data = (test_images,test_labels),
----> 3           callbacks = [checkpoint])
。。。more ouput。。。

再执行

last_meta = load_meta("./results/pointnet.h5")
last_meta
{'acc': [0.658],
 'epochs': [0],
 'loss': [1.1578046548366547],
 'training_args': '{}',
 'val_acc': [0.79],
 'val_loss': [0.7134194440841675]}

果然,就记录到第1次输出的时候。

创建一个函数来加载关键数据:

def get_last_status(model):
    last_epoch = -1
    last_meta = {}
    if os.path.exists("./results/pointnet.h5"):
        model.load_weights("./results/pointnet.h5")
        last_meta = load_meta("./results/pointnet.h5")
        last_epoch = last_meta.get('epochs')[-1]
    return last_epoch, last_meta
last_epoch, last_meta = get_last_status(model)
last_epoch
0

这个输出结果是正确的,我们只要从,第last_epoch+1次继续训练就好。val_accval_loss等都会被妥善在on_train_begin时处理好。

再次构建一个带有meta属性的回调函数:

checkpoint = MetaCheckpoint('./results/pointnet.h5', monitor='val_acc',
                            save_weights_only=True, save_best_only=True,
                            verbose=1, meta=last_meta)

重新训练:(指定起始epoch)

model.fit(train_images, train_labels,  epochs = 10,
          validation_data = (test_images,test_labels),
          callbacks = [checkpoint],
          initial_epoch=last_epoch+1)
Train on 1000 samples, validate on 1000 samples
Epoch 2/10
1000/1000 [==============================] - 0s 308us/step - loss: 0.4211 - acc: 0.8840 - val_loss: 0.5157 - val_acc: 0.8450

Epoch 00002: val_acc improved from 0.79000 to 0.84500, saving model to ./results/pointnet.h5
Epoch 3/10
1000/1000 [==============================] - 0s 274us/step - loss: 0.2882 - acc: 0.9220 - val_loss: 0.5238 - val_acc: 0.8240

Epoch 00003: val_acc did not improve from 0.84500
Epoch 4/10
1000/1000 [==============================] - 0s 277us/step - loss: 0.2098 - acc: 0.9500 - val_loss: 0.4674 - val_acc: 0.8470

Epoch 00004: val_acc improved from 0.84500 to 0.84700, saving model to ./results/pointnet.h5
Epoch 5/10
1000/1000 [==============================] - 0s 275us/step - loss: 0.1503 - acc: 0.9680 - val_loss: 0.4215 - val_acc: 0.8640

Epoch 00005: val_acc improved from 0.84700 to 0.86400, saving model to ./results/pointnet.h5
Epoch 6/10
1000/1000 [==============================] - 0s 279us/step - loss: 0.1081 - acc: 0.9830 - val_loss: 0.4051 - val_acc: 0.8680

Epoch 00006: val_acc improved from 0.86400 to 0.86800, saving model to ./results/pointnet.h5
Epoch 7/10
1000/1000 [==============================] - 0s 272us/step - loss: 0.0761 - acc: 0.9920 - val_loss: 0.4186 - val_acc: 0.8650

Epoch 00007: val_acc did not improve from 0.86800
Epoch 8/10
1000/1000 [==============================] - 0s 269us/step - loss: 0.0558 - acc: 0.9970 - val_loss: 0.4088 - val_acc: 0.8700

Epoch 00008: val_acc improved from 0.86800 to 0.87000, saving model to ./results/pointnet.h5
Epoch 9/10
1000/1000 [==============================] - 0s 269us/step - loss: 0.0486 - acc: 0.9990 - val_loss: 0.3960 - val_acc: 0.8730

Epoch 00009: val_acc improved from 0.87000 to 0.87300, saving model to ./results/pointnet.h5
Epoch 10/10
1000/1000 [==============================] - 0s 266us/step - loss: 0.0354 - acc: 1.0000 - val_loss: 0.4058 - val_acc: 0.8700

Epoch 00010: val_acc did not improve from 0.87300

可以看见,确实是从第2个epoch开始训练的。

这!就是我们想要的效果。

完整的程序

https://github.com/HarborZeng/resume_traning


   转载规则


《机器学习tensorflow-keras之如何优雅的从上次断掉的地方继续训练》 Harbor Zeng 采用 知识共享署名 4.0 国际许可协议 进行许可。
 上一篇
为什么是静态博客 为什么是静态博客
什么是静态博客所谓静态博客,即通过工具,直接将作者所书写的博文编译成最终的html,css,js等文件。作者/博主,只需将生成的文件部署在静态server上面即可被在互联网中访问。 而传统的数据库型博客对服务器的要求就比较大了 使用静态博客生成工具 用户通过浏览器访问服务器,直接就回获得已编译的静态资源。 静态博客的好处 因为用户在浏览器上访问博客时,只用从服务器(如nginx)拿来编译好
下一篇
机器学习tensorflow-keras之保存和恢复模型h5py 机器学习tensorflow-keras之保存和恢复模型h5py
前言模型进度可在训练期间和之后保存。这意味着,您可以从上次暂停的地方继续训练模型,避免训练时间过长。此外,可以保存意味着您可以分享模型,而他人可以对您的工作成果进行再创作。发布研究模型和相关技术时,大部分机器学习从业者会分享以下内容: 用于创建模型的代码 模型的训练权重或参数 分享此类数据有助于他人了解模型的工作原理并尝试使用新数据自行尝试模型。 数据和依赖依赖安装并导入 TensorFlow
2019-02-16
  目录
